Your current position:Home >> Procucts >> Wind- proof and dust-control net >> windbreak

windbreak

2012-02-06 13:45:05 Source:Hebei BangDa Metal Products Co.,Ltd Browse:2919



USES: used in filter of automobiles internal-combustion engine, sieving of mine,
medicine,grainúČetc.



Characteristic:


Wind Dust Network is a new product which made of perforated metal and can significantly reduce the wind speed, and the dust . Compared with the rigid structure of the wall ,Wind dust network is more efficient and economic.

Wind dust net : includes single peak wind dust net, twins peaks wind dust net and three peaks wind dust net.

Application:

1. Power plants, coal mines, coking plants, coal washing plant, and other businesses to save coal field
2. Ports, terminals and markets a variety of coal storage yard
3. Iron and steel, building materials, cement companies such as a variety of open-air yard
4. Coal storage and station of Railway and highway transportation
5. Sites, road dust.

Single peak wind dust netú║


Width 270mm-450mm
Peak of high: 50mm-85mm,
Length: 0-6.2m.
Plate thickness 0.5mm-1.5mm.
We can produce according to customer's requirements.
Material: steel plate, galvanized plate, color coated sheet, stainless steel sheet.
Surface treatment: electrostatic powder coating.

Three peaks wind dust netú║COST-EFFECTIVE SIZE IS: HS-810  THICKNESS0.7MM
Width 810mm-910mm
Peak of high: 50mm-80mm,
Length: 0-6.2m.
Plate thickness 0.5mm-1.5mm.
We can produce according to customer's requirements.
Material: steel plate, galvanized plate, color coated sheet, stainless steel sheet.
Surface treatment: electrostatic powder coating.
